Bonney Forge Valve – The Bonney Forge 3/4″ HL-11-SW GATE LE is a high-performance Class 800 forged steel gate valve featuring a bolted bonnet, standard/full port design, socket weld connection, and low emission (LE) packing. Built in accordance with API 602, ASME B16.34, and BS 5352 standards, it offers exceptional reliability, integral backseat protection, and tight sealing under high pressure and temperature conditions in industrial piping systems.
Bonney Forge Valve 3/4″ HL-11-SW
Product Specifications
| Brand | Bonney Forge |
|---|---|
| Item / Part No. | 3/4″ HL-11-SW GATE LE |
| Valve Type | Gate Valve (Bolted Bonnet, Standard / Full Port, OS&Y) |
| Size / Dimensions | 3/4 Inch (DN 20) |
| Pressure Class | Class 800 (1975 psig @ 100°F / 138 bar @ +38°C) |
| Connection Type | Socket Weld Ends to ASME B16.11 |
| Body / Bonnet Material | A 105 / Trim F6/HF |
| Stem & Seat Material | Stem: ASTM A479 410 | Seat: ASTM A479 410 HF |
| Wedge Material | ASTM A182 F6a |
| Design Standards | API 602 – ASME B16.34 – BS 5352 (Tested to API 598, Marking MSS SP25) |
